Blue Sea 2356100 - Water Resistant 100A Busbar w/Cover

Blue Sea 2356100 - Water Resistant 100A Busbar w/Cover

SKU BLU2356100
Brand Blue Sea
Availability :
0 In Stock, Available for Order
$44.99 - $44.99
$44.99
$44.99 - $44.99
$44.99

Simple Returns & Same Day Shipping*

30-Day Return Policy. In-stock items ship same day if ordered by 2:00 PM ET. Place overnight & 2-day orders by 1:00 PM ET. Orders after these times ship the next business day. *Shipping Policy

Need It Fast?

We offer Local Delivery & Expedited Shipping through our trusted logistics partners, as well as FREE In-Store Pick Up.

Need Help From Our Sales Team?

Available during our normal business hours:

2356100 - Water Resistant 100A Busbar with Cover

Water-resistant bussing for harsh environments. Built with wing screws for toolless access.

Features:

  • Accepts a wide range of wire sizes
    • Includes 3 wire plugs to maintain a water-resistant rating if less than 4 wires are used
    • Nests with other water-resistant 100A common busbars and ST-Blade water resistant fuse block for space-saving wiring
    • Ideal for positive distribution and for the collection of negative or AC ground circuits
    • Meets ABYC/USCG insulation requirements
    • Tin-plated copper busses and fuse clips
    • Includes four (4) write-on circuit labels
    • Small format standard and custom labels are available
    • Wing-screws designed for tool-free installation of cover to meet ABYC compliance

Technical Specifications:

  • Cover - yes
  • Maximum Voltage - 300V AC - 48V DC
  • Terminal Stud - 1 x #10-32
  • Continuous Rating - 100A AC or DC
  • Bus Material - Tin-plated Copper
  • Mounting Holes - Accepts 1/4" (6mm) screws
  • Terminal Screws - 4 x # 8-32
  • Wire Size - Input - (1) 8 AWG to 4 AWG
  • Wire Size - Load - (4) 16 AWG to 10 AWG

In the Box:

  • 2356100 Busbar
  • Instruction Manual

*Sold as an Individual

Brand: Blue Sea

Ship Length: 4.96

Ship Width: 3.4

Ship Height: 2.1
